Intel Core i7-12700KF 12th Gen up to 5 GHz 12 Core and 20 Threads

Model: i7-12700KF
Maximum Boost Speed: 5 GHz (P-Core 4.9 GHz, E-Core 3.8 GHz)
Base Clock Speed: P-Core 3.6GHz & E-Core 2.7GHz
Cache: 25MB, Socket: LGA 1700
CPU Cores: 12, CPU Threads: 20
Product Collection: 12th Generation Intel® Core™ i7 Processors
Code Name: Products formerly Alder Lake
Vertical Segment: Desktop
Processor Number: i7-12700KF
Status: Launched
Launch Date: Q4'21
Lithography: Intel 7
Use Conditions: PC/Client/Tablet
CPU Specifications:

• Total Cores: 12
• # of Performance-cores: 8
• # of Efficient-cores: 4
• Total Threads: 20
• Max Turbo Frequency: 5.00 GHz
• Intel® Turbo Boost Max Technology 3.0 Frequency ‡: 5.00 GHz
• Performance-core Max Turbo Frequency: 4.90 GHz
• Efficient-core Max Turbo Frequency: 3.80 GHz
• Performance-core Base Frequency: 3.60 GHz
• Efficient-core Base Frequency: 2.70 GHz
• Cache: 25 MB Intel® Smart Cache
• Total L2 Cache: 12 MB
• Processor Base Power: 125 W
• Maximum Turbo Power: 190 W

Supplemental Information:

• Embedded Options Available: No

Memory Specifications:

• Max Memory Size (dependent on memory type): 128 GB
• Memory Types: Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
• Max # of Memory Channels: 2
• Max Memory Bandwidth: 76.8 GB/s

Expansion Options:

• Direct Media Interface (DMI) Revision: 4
• Max # of DMI Lanes: 8
• Scalability: 1S Only
• PCI Express Revision: 5.0 and 4.0
• PCI Express Configurations ‡: Up to 1x16+4 | 2x8+4
• Max # of PCI Express Lanes: 20

Package Specifications:

• Sockets Supported: FCLGA1700
• Max CPU Configuration: 1
• Thermal Solution Specification: PCG 2020A
• TJUNCTION: 100°C
• Package Size: 45.0 mm x 37.5 mm

Advanced Technologies:

• Intel® Gaussian & Neural Accelerator: 3
• Intel® Thread Director: Yes
• Intel® Deep Learning Boost (Intel® DL Boost): Yes
• Intel® Optane™ Memory Supported ‡: Yes
• Intel® Speed Shift Technology: Yes
• Intel® Turbo Boost Max Technology 3.0 ‡: Yes
• Intel® Turbo Boost Technology ‡: 2
• Intel® Hyper-Threading Technology ‡: Yes
• Intel® Virtualization Technology (VT-x) ‡: Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) ‡: Yes
• Intel® VT-x with Extended Page Tables (EPT) ‡: Yes
• Intel® 64 ‡: Yes
• Instruction Set: 64-bit
• Instruction Set Extensions: Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2
• Idle States: Yes
• Enhanced Intel SpeedStep® Technology: Yes
• Thermal Monitoring Technologies: Yes
• Intel® Volume Management Device (VMD): Yes

Security & Reliability:

• Intel® AES New Instructions: Yes
• Secure Key: Yes
• Intel® OS Guard: Yes
• Execute Disable Bit ‡: Yes
• Intel® Boot Guard: Yes
• Mode-based Execute Control (MBE): Yes
• Intel® Control-Flow Enforcement Technology: Yes
